DIMENSIONS

W H BASE MODEL NO.
23 5/8″ 8 1/2″ S7352-L24
23 5/8″ 8 1/2″ S7352-L24A
23 5/8″ 8 1/2″ S7352-3N15 (Lamps by others)
SPECIFICATIONS

Voltage:
L24 – 120/277V, 0-10V 1% Dimming
L24A – 120V Phase Dim – AND 120/277V 0-10V Dimming (Driverless LED)
3N15 – 120V
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Molded Opal Glass Lens
• Spun Metal Housing
• S7352-L24 Only – 0-10V 1% Dimming
• S7352-L24A Only – 120V Phase Dimming and 120/277V 0-10V Dimming (Driverless 24W LED)
• S7352-3N15 Only – (3) E26 Sockets for up to 15W LED Lamps (by others)

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + CCT + Finish + Option Code

S7352-L24 + 27K + PT + Option
S7352-L24A 30K
35K
40K
S7352-3N15 + PT
FINISHES

PT Powder Coated Finishes*

*(Specify Color Code from the list of Finishes – ie. White would be ‘WH’)
OPTIONS

EML Remote 10W Emergency LED Battery Backup (Requires Additional Power Cable)
