Model No. + Lamp Code CCT Finish Option Code
LW111-L18  27K PT Powder Coated* EML Emergency 10W LED Battery
30K BA Brushed Aluminum Driver (Remote)
35K PC Polished Chrome
40K NT Nickel Touch
GT Gold Touch
ZT Bronze Touch
CT Coper Touch
PWT Pewter Touch
BST Blackened Steel Touch
CC Custom Painted Finish *(Specify Color Code from the list of Powder Coating Finishes)

DIMENSIONS

BASE MODEL NO. H W D
LW111-L18 18″ 10″ 4″
SPECIFICATIONS

Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Opal Matte Acrylic
• Solid Aluminum Material
• LED 0-10V Dimming Driver

LIGHT OUTPUT

LXX = ~ 65 LPW Delivered Lumens (Example: L18= 18 x 65 = 1,170 Lumens)
