Model No. + Lamp Code | CCT | Finish*** | |
LW105-2L05A | 27K | PT Powder Coated* | |
LW105-2N20** | 30K | BA Brushed Aluminum | |
LW105-2GU24** | 35K | PC Polished Chrome | |
40K | NT Nickel Touch | ||
GT Gold Touch | |||
ZT Bronze Touch | |||
CT Copper Touch | *(Specify Color Code from the list of | ||
TT Toffee Touch | Powder Coating Finishes) | ||
PWT Pewter Touch | **(Lamps by Others) | ||
BST Blackened Steel Touch | ***(Finish Selection is for Canopy, Bracket and Socket Cup | ||
CC Custom Painted Finish | Vertical Stems are Matte Black) |
DIMENSIONS
BASE MODEL NO. | H | W | D |
LW105 | 24″ | 11″ | 4 1/4″ |
SPECIFICATIONS
Electrical: 120V Only. (2L05A Version is ELV Dimmable)
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.
FEATURES
• Opal Matte Glass
LIGHT OUTPUT
2L05A indicates (2) integral line-voltage LED discs totaling nominal 10W @ ~45LPW delivered.
LXX = ~ 45 LPW Delivered Lumens (Example: L10 = 10W x 45LPW = 450 Lumens)
