Model No. + Lamp Code CCT Finish OA Option Code
LH114-L12 27K PT Powder Coated* ‘OA’ + Overall Height in Inches (ie. OA96) EML Emergency 10W LED Battery
30K BA Brushed Aluminum Driver (Remote)
35K PC Polished Chrome
40K NT Nickel Touch
GT Gold Touch
ZT Bronze Touch
CT Coper Touch
PWT Pewter Touch
BST Blackened Steel Touch
CC Custom Painted Finish *(Specify Color Code from the list of Powder Coating Finishes)

DIMENSIONS

BASE MODEL NO. H W D
LH114-L12 16 3/4″ 12 3/4″ 12 3/4″
SPECIFICATIONS

Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Opal Matte Glass
• Open Aluminum Frame
• Adjustable Aircraft Cables
• Clear Silver Braided Cord
• LED 0-10V Dimming Driver

LIGHT OUTPUT

LXX = ~ 88 LPW Delivered Lumens (Example: L12= 12 x 88 = 1,056 Lumens)
