DIMENSIONS

W H D MC BASE MODEL NO.
6 1/2″ 22″ 5 1/2″ 11″ S9355-L12
8 1/2″ 37″ 7 7/8″ 18 1/2″ S9356-L16
SPECIFICATIONS

Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided. Silicone Seal Required  (by others).

FEATURES

• Opal Acrylic
• Solid Aluminum Material
• Solid Aluminum End Caps
• Solid Aluminum Accent Bars
• UL Listed for Wet Location
• LED 0-10V Dimming Driver

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + CCT + Finish + Option Code

S9355-L12 + 27K + PT + Option
S9356-L16 30K BA
35K BN
40K
FINISHES

BA Brushed Aluminum
BN Brushed Nickel
PT Powder Coated Finishes*
**
*(Specify Color Code from the list of Powder Coating Finishes [except interior only metallics])
OPTIONS

BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup

LIGHT OUTPUT

LXX = ~ 69 LPW Delivered Lumens (Example: L12= 12W x 69LPW = 828 Lumens)

** Try our new Shimmer Metalic Paints, Formulated for Exterior Conditions.
