Print This PageDIMENSIONS
| W | H | D | MC | BASE MODEL NO. |
| 11 3/4″ | 19″ | 11″ | 9 5/8″ | S9315-L24 |
SPECIFICATIONS
Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided. Silicone Seal Required (by others).
FEATURES
• Solid Aluminum Material
• UL Listed for Wet Location
• LED 0-10V Dimming Driver
ORDER AS A COMPLETE UNIT:
Model No. + Lamp Code + CCT + Housing Finish + Accent Bar Finish + Option Code
| S9315-L24 | + | 27K | + | PT | + | PT | + | Option |
| 30K | BA | BA | ||||||
| 35K | ||||||||
| 40K |
HOUSING FINISHES
| BA Brushed Aluminum | PT Powder Coated Finishes* ** |
| *(Specify Color Code from the list of Powder Coating Finishes [except interior only metallics]) | |
ACCENT BARS FINISHES
| BA Brushed Aluminum | PT Powder Coated Finishes* ** |
| *(Specify Color Code from the list of Powder Coating Finishes [except interior only metallics]) | |
OPTIONS
BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup
LIGHT OUTPUT
LXX = ~ 48 LPW Delivered Lumens (Example: L24= 24W x 48LPW = 1152 Lumens)
** Try our new Shimmer Metalic Paints, Formulated for Exterior Conditions.
