DIMENSIONS

W H D MC BASE MODEL NO.
6″ 16″ 4″ 8″ S9265-L24
6″ 24″ 4″ 12″ S9266-L32
SPECIFICATIONS

Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided. Silicone Seal Required  (by others).

FEATURES

• Opal Acrylic Lens
• Solid Aluminum Bar Stock Material
• UL Listed for Wet Location
• LED 0-10V Dimming Driver

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + CCT + Finish + Option Code

S9265-L24 + 27K + PT + Option
S9266-L32 30K BA
35K
40K
FINISHES

BA Brushed Aluminum PT Painted Finishes*
**
*(Specify Color Code from Our Standard Finish Chart)
OPTIONS

EML Emergency Battery Pack with LED Lighting (Remote)

LIGHT OUTPUT

LXX = ~ 75 LPW Delivered Lumens (Example: L24= 24 x 75 = 1,800 Lumens)

** Try our new Shimmer Metalic Paints, Formulated for Exterior Conditions.
