DIMENSIONS

Dia H BASE MODEL NO.
8″ 6 1/2″ S7240-L10
12″ 11″ S7241-L10
18″ 16 3/4″ S7242-L16
22″ 20 5/8″ S7243-L24
SPECIFICATIONS

Driver: REMOTE Mounted 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Opal Matte Acrylic Diffuser
• LED 0-10V Dimming Driver

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + Finish Code + OA + Option Code

S7240-L10 + 27K + Option
S7241-L10 30K
S7242-L16 35K
S7243-L24 40K
OPTIONS

EML Remote 10W Emergency LED Battery Backup (Requires Additional Power Cable)

LIGHT OUTPUT

LXX = ~ 119 LPW Delivered Lumens (Example: L10= 10W x 119LPW = 1,190 Lumens)
