DIMENSIONS

W H BASE MODEL NO.
13 1/8″ 5 5/8″ S7225-L12
17 1/4″ 6 3/4″ S7226-L24
SPECIFICATIONS

Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Opal Matte Acrylic
• Heavy Gauge Spun Metal Housing Trim
• Solid Metal Bar Trim
• LED 0-10V Dimming Driver

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + CCT + Finish + Option Code

S7225-L12 + 27K + PT ZT + Option
S7226-L24 30K BB TT
35K BC PWT
40K CT BST
GT CC
NT
FINISHES
BB Brushed Brass
BC Brushed Chrome
CT Copper Touch
NT Nickel Touch
GT Gold Touch
ZT Bronze Touch		 TT Toffee Touch
PWT Pewter Touch
BST Blackened Steel Touch
CC Custom Painted Finish
PT Powder Coated Finishes*
*(Specify Color Code from the list of Powder Coating Finishes)
OPTIONS

BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup (Requires Additional Power Cable)

LIGHT OUTPUT

LXX = ~ 98 LPW Delivered Lumens (Example: L12= 12W x 98LPW = 1,176 Lumens)
