DIMENSIONS

W H BASE MODEL NO.
18″ 7″ S7210-L18
18″ 7″ S7210-L24
26″ 8″ S7211-L24
SPECIFICATIONS

Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Opal Matte Acrylic
• Heavy Gauge Spun Metal Trim
• LED 0-10V Dimming Driver

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + CCT + Finish + Option Code

S7210-L18 + 27K + PT + Option
S7210-L24 30K BA
S7211-L24 35K BB
40K BC
BN
FINISHES

BA Brushed Aluminum
BB Brushed Brass
BC Brushed Chrome
BN Brushed Nickel
PT Painted Finishes*
*(Specify Color Code from the list of Powdercoat finishes [except interior only metallics])
OPTIONS

EM Emergency Battery Pack with Fluorescent Lighting (Remote)
FAA Faux Alabaster Acrylic (Hand Painted) (FA-1 White; FA-2 Antique; FA-3 Grey; FA-4 Taupe; FA-5 Honey; FA-6 Tuscan

LIGHT OUTPUT

LXX = ~ 89 LPW Delivered Lumens (Example: L18= 18 x 89 = 1,602 Lumens)
