DIMENSIONS
W | H | BASE MODEL NO. |
16 1/2″ | 4 3/4″ | S7100-L16 |
21 1/2″ | 6 3/4″ | S7100-L24 |
SPECIFICATIONS
Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.
FEATURES
• Venetian Glass
• LED 0-10V Dimming Driver
ORDER AS A COMPLETE UNIT:
Model No. + Lamp Code + CCT + Finish + Option Code
S7100-L16 | + | 27K | + | PT | + | Option |
S7101-L24 | 30K | BA | ||||
35K | BC | |||||
40K | PB | |||||
PC | ||||||
FINISHES
BA Brushed Aluminum BC Brushed Chrome PB Polished Brass |
PC Polished Chrome PT Powder Coated Finishes* |
*(Specify Color Code from the list of Powder Coating Finishes) |
OPTIONS
BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup (Requires Additional Power Cable)
LIGHT OUTPUT
LXX = ~ 63 LPW Delivered Lumens (Example: L16= 16W x 63LPW = 1,008 Lumens)
