Print This PageDIMENSIONS
| W | H | D | MC | BASE MODEL NO. |
| 4 1/2″ | 24″ | 4″ | 12″ | S3B75-24-2L07 |
| 4 1/2″ | 30″ | 4″ | 15″ | S3B75-30-2L07 |
| 4 1/2″ | 36″ | 4″ | 18″ | S3B75-36-2L07 |
| 4 1/2″ | 42″ | 4″ | 21″ | S3B75-42-2L07 |
| 4 1/2″ | 48″ | 4″ | 24″ | S3B75-48-2L07 |
SPECIFICATIONS
Voltage: 120V or 277V, (120V: Phase Dimming or 0-10V Dimming) (277V: 0-10V Dimming)
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.
FEATURES
• 90 CRI
• ADA Compliant
• Two Tone Color Schemes
• Dimming: 0-10V (120/277V) or Phase Dimming (120V only)
ORDER AS A COMPLETE UNIT:
Model No. + Lamp Code + CCT + Exterior Finish + Interior Finish + Option Code
FINISHES
PT Powder Coated Finishes*
XT Trending Brushed Metal Finishes*
CC Custom Painted Finish
*(Specify Color Code from the list of Finishes – ie. Gold Touch would be ‘GT’)
OPTIONS
BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup
