Print This PageDIMENSIONS
| W | MC | H | D | BASE MODEL NO. |
| 22″ | 1 3/8″ | 3 3/8″ | 3 3/4″ | S3A85-L16 |
| 34″ | 1 3/8″ | 3 3/8″ | 3 3/4″ | S3A86-L24 |
| 46″ | 1 3/8″ | 3 3/8″ | 3 3/4″ | S3A87-L32 |
SPECIFICATIONS
Driver: 0-10V Dimming to 1%, 120/277
Mounting: Mounts to 2″ x 4″ Junction Boxes (by others) With Hardware Provided.
FEATURES
• Integral Driver
• ADA Compliant
• Horizontal or Vertical Mounting
• UL Listed for Damp Location
• LED 0-10V Dimming Driver
ORDER AS A COMPLETE UNIT:
Model No. + Lamp Code + Finish Code
| S3A85‑L16 | + | 27K | + | PT | ZT |
| S3A86‑L24 | 30K | BA | TT | ||
| S3A87‑L32 | 35K | GT | PWT | ||
| 40K | CT | BST | |||
| NT | |||||
FINISHES
| BA Brushed Aluminum NT Nickel Touch GT Gold Touch ZT Bronze Touch CT Copper Touch |
TT Toffee Touch PWT Pewter Touch BST Blackened Steel Touch CC Custom Painted Finish PT Powder Coated Finishes* |
| *(Specify Color Code from the list of Powder Coating Finishes) | |
OPTIONS
BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup
LIGHT OUTPUT
LXX = ~ 92 LPW Delivered Lumens (Example: L16= 16W x 92LPW = 1,472 Lumens)
