DIMENSIONS

W H D MC BASE MODEL NO.
24″ 4 1/2″ 5 1/2″ 2 3/8″ S3720-L16
33″ 4 1/2″ 5 1/2″ 2 3/8″ S3721-L18
41″ 4 1/2″ 5 1/2″ 2 3/8″ S3722-L27
SPECIFICATIONS

Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Opal Matte Acrylic
• LED 0-10V Dimming Driver

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + CCT + Finish + Option Code

S3720-L16 + 27K + PT CT + Option
S3721-L18 30K BA GT
S3722-L27 35K BB NT
40K BC ZT
BN
FINISHES

BA Brushed Aluminum
BB Brushed Brass
BC Brushed Chrome
CT Copper Touch
GT Gold Touch
NT Nickel Touch
ZT Bronze Touch
BN Brushed Nickel
PT Painted Finishes*
*(Specify Color Code from the list of Powdercoat finishes [except interior only metallics])
OPTIONS

EML Emergency Battery Pack with LED Lighting (Remote)
FAA Faux Alabaster Acrylic (Hand Painted) [FA-1 White; FA-2 Antique; FA-3 Grey; FA-4 Taupe; FA-5 Honey; FA-6 Tuscan]

LIGHT OUTPUT

LXX = ~ 69 LPW Delivered Lumens (Example: L16= 16 x 69 = 1,104 Lumens)
