DIMENSIONS

W H D MC BASE MODEL NO.
12″ 5″ 9″ 2 1/2″ S3030-L22
18″ 5″ 9″ 2 1/2″ S3031-L32
SPECIFICATIONS

Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Fabricated Heavy Gauge Cold Rolled Steel
• LED 0-10V Dimming Driver

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + CCT + Finish + Option Code

S3030-L22 + 27K + PT + Option
S3031-L32 30K
35K
40K
FINISHES

PT Painted Finishes*
*(Specify Color Code from Our Standard Finish Chart)

OPTIONS

EML Emergency Battery Pack with LED Lighting (Remote)
CTG Cleared Tempered Glass Lens

LIGHT OUTPUT

LXX = ~ 115 LPW Delivered Lumens (Example: L22= 22 x 115 = 2,530 Lumens)
