| W | H | D | X | BASE MODEL NO. |
| 36″ | 4-1/4″ | 4-1/4″ | 48″ | S2A31-L144-72U |
| 48″ | 4-1/4″ | 4-1/4″ | 48″ | S2A32-L192-96U |
| 60″ | 4-1/4″ | 4-1/4″ | 48″ | S2A33-L248-124U |
| 72″ | 4-1/4″ | 4-1/4″ | 48″ | S2A34-L288-144U |
Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided. Larger units require additional structural blocking.
• High Transmission Opal Lens in both Direct and Indirect positions
• Extruded Aluminum Housing
• Clear Silver Braided Cord with Adjustable Aircraft Cables
• Integral Driver
• LED 0-10V Dimming Driver
Model No. + Lamp Code + CCT + Finish + OA + Option Code
| S2A31-L144-72U | + | 27K | + | PT | + | OA | + | Option |
| S2A32-L192-96U | 30K | CC | ||||||
| S2A33-L248-124U | 35K | BA | ||||||
| S2A34-L288-144U | 40K | NT | ||||||
| GT | ||||||||
| CT | ||||||||
| ZT | ||||||||
| PWT | ||||||||
| BST |
| BA Brushed Aluminum ZT Bronze Touch NT Nickel Touch GT Gold Touch CT Copper Touch |
PWT Pewter Touch BST Blackened Steel Touch CC Custom Painted Finish PT Powder Coated Finishes* |
| *(Specify Color Code from the list of Powder Coating Finishes) | |
BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup
MCR Minimal Canopy – Remote Driver Option (4 Vertical Cables)
2C 2 Circuit – Direct/Indirect Separately Switched
OA Specify Overall Height of Fixture in Inches; E.G. – OA48
LXX = ~ 70 LPW Down and ~ 78LPW Up Delivered Lumens (Example: L84= 84 x 70 = 5,880 Lumens Down and L42= 42 x 78 = 3,276 Lumens Up)
