Print This PageDIMENSIONS:
| L | W | H | OA | BASE MODEL NO. |
| 2′ | 2¼” | 12″ | 60″ | S2995-L32-16U |
| 2′ | 2¼” | 12″ | 60″ | S2995-L16 |
| 4′ | 2¼” | 12″ | 60″ | S2996-L64-32U |
| 4′ | 2¼” | 12″ | 60″ | S2996-L32 |
| 6′ | 2¼” | 12″ | 60″ | S2997-L96-48U |
| 6′ | 2¼” | 12″ | 60″ | S2997-L48 |
| 8′ | 2¼” | 12″ | 60″ | S2998-L128-64U |
| 8′ | 2¼” | 12″ | 60″ | S2998-L64 |
Drawings indicate proportional scaling of nominal lengths:
| 2′ | |||||||||||
| 4′ | |||||||||||
| 6′ | |||||||||||
| 8′ |
FEATURES
• 8′ Lengths have (3) AC Cables
• Optional Direct or Direct/Indirect Distribution
• Internal Extruded Aluminum LED Housing
• 3/8″ Felt Panels – NRC Rating = > .70
• Opal Silicone Lenses
• (2) AC Cable and Cord Suspension
• LED 0-10V 1% Dimming Driver – Integral
ORDER AS A COMPLETE UNIT:
Model No. + Lamp Code + CCT + Trim Finish + Felt Fabric + OA + Option Code
| S2995-L32-16U | + | 27K | + | PT | + | F01 | F11 | + | OA | + | Option |
| S2995-L16 | 30K | CC | F02 | F12 | |||||||
| S2996-L64-32U | 35K | BA | F03 | F13 | |||||||
| S2996-L32 | 40K | NT | F04 | F14 | |||||||
| S2997-L96-48U | GT | F05 | F15 | ||||||||
| S2997-L48 | ZT | F06 | |||||||||
| S2998-L128-64U | CT | F07 | |||||||||
| S2998-L64 | PWT | F09 | |||||||||
| BST | F10 |
TRIM FINISHES
| BA Brushed Aluminum CT Copper Touch NT Nickel Touch GT Gold Touch ZT Bronze Touch |
PWT Pewter Touch BST Blackened Steel Touch CC Custom Painted Finish PT Powder Coated Finishes* |
| *(Specify Color Code from the list of Powder Coating Finishes) | |
FELT FABRIC
| F01 Midnight F02 Iron F03 Granite F04 Steel F05 Coin |
F06 Lunar F07 Cool F08 Bronze F09 Camel F10 Royal |
F11 Navy F12 Scarlet F13 Forest F14 Lemon F15 Orange |
OPTIONS
BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Emergency Battery Pack for LED Lighting (Remote Only)
BK2 Black Power Cable with (2) Aircraft Cables
WH2 Black Power Cable with (2) Aircraft Cables
LIGHT OUTPUT
LXX = ~ 75 LPW Delivered Lumens (Example: L64= 64 x 75 = 4,800 Lumens)
