| W | H | X | BASE MODEL NO. |
| 4 1/2″ | 96″ | 24″ | S2910-L24 |
| 4 1/2″ | 96″ | 36″ | S2911-L36 |
| 4 1/2″ | 96″ | 48″ | S2912-L48 |
| 4 1/2″ | 120″ | 72″ | S2913-L72 |
| 4 1/2″ | 144″ | 96″ | S2914-L96 |
Driver: 0-10V dimming to 1%, 120/277 [Excluding Downlight]
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) with Hardware Provided
• Opal Matte Acrylic Rectilinear Shade
• Clear Silver Braided Cord with (2) Adjustable Aircraft Cable
• LED 0-10V Dimming Driver
Model No. + Lamp Code + Finish + OA + Option Code
| S2910-L24 | + | 27K | + | PT | ZT | + | OA | + | Option |
| S2911-L36 | 30K | BA | CT | ||||||
| S2912-L48 | 35K | PC | PWT | ||||||
| S2913-L72 | 40K | NT | BST | ||||||
| S2914-L96 | GT | CC |
| BA Brushed Aluminum PC Polished Chrome NT Nickel Touch GT Gold Touch ZT Bronze Touch |
CT Copper Touch PWT Pewter Touch BST Blackened Steel Touch CC Custom Painted Finish PT Powder Coated Finishes* |
| *(Specify Color Code from the list of Powder Coating Finishes) | |
BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup
OA Specify Overall Height of Fixture in Inches; E.G. – OA48
SWC 45-Degree Swivel Canopy
1S Single Stem
P20S – Optional PAR 20 short downlight with GU24 socket (120V only) on separate circuit.
BK2 – Black Cord with (2) Adjustable Aircraft Cable
WH2 – White Cord with (2) Adjustable Aircraft Cable
LXX = ~ 93 LPW Delivered Lumens (Example: L24= 24W x 93LPW = 2,232 Lumens)
