Print This PageDIMENSIONS
| W | H | X | BASE MODEL NO. |
| 36″ | 24″ | 6.5″ | S2566-L64 |
FEATURES
Drivers: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) with Hardware Provided
FEATURES
• Illuminated Acrylic Baffle Rings
• White SJ Cord with (4) Aircraft Cables
• Cold Rolled Steel
• LED 0-10V Dimming Drivers
ORDER AS A COMPLETE UNIT:
Model No. + Lamp Code + Finish + OA + Option Code
| S2566-L64 | + | 27K | + | PT | + | Option |
| 30K | ||||||
| 35K | ||||||
| 40K |
FINISHES
| PT Powder Coated Finishes* | |
| *(Specify Color Code from the list of Powder Coating Finishes) | |
OPTIONS
BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup
OA Specify Overall Height of Fixture in Inches; e.g. – OA48
LIGHT OUTPUT
LXX = ~ 60 LPW Cylinder (Example: L64= 64W x 60LPW = 3,840 Lumens)
