DIMENSIONS

Dia X H BASE MODEL NO.
60″/48″/36″ 1 3/8″ 96″ S1070-L90-L78-L62
72″/60″/48″ 1 3/8″ 96″ S1071-L132-L90-L78
SPECIFICATIONS

Driver: 0-10V dimming to 1%, 120/277 (Drivers are Remote)
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) with Hardware Provided (Additional structural blocking required for weight)

FEATURES

• Silicone Opal Lens
• LED Downlight
• Clear Silver Braided Cord(s) with Adjustable Aircraft Cable(s)
• (3) Remote Driver Boxes above ceiling
• LED 0-10V 1% Dimming Drivers

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + Finish  + OA + Option Code

S1070-L90-L78-L62 + 27K + PT CT + OA + Option
S1071-L132-L90-L78 30K BA PWT
35K NT BST
40K GT TT
ZT CC
FINISHES

BA Brushed Aluminum
NT Nickel Touch
GT Gold Touch
ZT Bronze Touch
CT Copper Touch
PWT Pewter Touch
BST Blackened Steel Touch
TT Toffee Touch
CC Custom Painted Finish
PT Powder Coated Finishes*
*(Specify Color Code from the list of Powder Coating Finishes)
OPTIONS

EML Remote 10W Emergency LED Battery Backup
OA Specify Overall Height of Fixture in Inches; E.G. – OA96
BK12 Black Cord with (12) Adjustable Aircraft Cables
WH12 White Cord with (12) Adjustable Aircraft Cables

LIGHT OUTPUT

LXX = ~ 65 LPW Delivered Lumens (Example: L90= 90 x 65 = 5,850 Lumens)
