PART NUMBER
SR‑WG125- ___- ___- ___- ___- ___- ___- ___
Model No. Lamp Base Watts CCT
(If Applicable)		 Finish Beam
Spread		 Trim Finish Options
SR-WG125 L LED 05 27K BL Black N 15° AB Black DRP Drop Lens
08 30K WH White M 24° AW White EML Remote 10W
10 35K SV Silver F 36° AG Dark Gold Emergency LED
13 40K PT (Custom)* W 60° AC Chrome Battery Backup
16 DTW3K (Dim
19 to warm
3000K>2000K)

*(Consult Factory for more options)

DIMENSIONS
BASE MODEL NO. H Dia D
SR-WG125 10″ 3″ 4 3/4″
SPECIFICATIONS

Dimming: 0-10V Dimming to 1% or 120V ONLY/TRIAC Dimming
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Clean Appearance
• Down Light
• Beam Spread Options
• Trim Cone Options
• 90 CRI
• Lumen Output Nominal 95LPW

APPLICATIONS

• Kitchen
• Corridor
• Entry
• Bedroom
• Bath

Note: (Minimum Orders May Apply)
Don’t see an option you are looking for? Contact your agent to request a modification.
DOWNLOADS

 Product Cutsheet
