PART NUMBER
SR‑EX104- ___- ___- ___- ___
Model No.  LED or
Lamp Base		 Watts CCT
(If Applicable)		 Finish
SR-EX104 L LED 24 30K PT Powder Coated*
32 35K BB Brushed Brass
40 40K BN Brushed Nickel
AB Antique Brass

*(Specify Color Code from the list of Powder Coating Finishes)
**(Consult Factory for more options)

DIMENSIONS
BASE MODEL NO. H W D MC
SR-EX104 7″ 13″ 6 7/8″ 3 1/2″
SPECIFICATIONS

Dimming: 0-10V Dimming, 120/277/(Consult factory for 347V)
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided. Silicone Seal Required (By Others).

FEATURES

• 3000/3500/4000K on-board optional CCT
• 24/32/40W on-board optional outputs
• IP65 Rating
• Type 3 Distribution Pattern
• Tempered Glass Lens
• Downlight Suitable for Wet Location
• Uplight Suitable for Damp Location
• UL Listed for Wet Location
• Full Cut-off Distribution
• ELV Dimming

APPLICATIONS

• Building Exterior
• Entry Way

SPECIAL FEATURES (these features come on all models)
3 Color Temperatures
On board switch allows for on-site adjustment to 3000/3500K/4000K options.

Note: For factory Pre-set, please indicate the CCT
in the part number (ex: SR-EX104-L24-35K-BL)
3 Power Levels
On Board Switch allows for on-site adjustment to 3 power levels.

40W/32W/24W

Note: For Factory Pre-Set Watts, please indicate the Watts
in the part number (ex: SR-EX104-L32-30K-BZ)
Photosensor
On Board Sensor and Switch allows an internal photocell to be turned on or off as needed.

NOTE: For Factory Pre-Set to ON, please indicate
in the part number (ex: SR-EX104-L24-40K-BST-PS)
Don’t see an option you are looking for? Contact your agent to request a modification.
