| Odraz Mirror | Diameter (in.) | Source | Frame Finish | Options |
| SM080 | 24R (24″) | L930K (Standard) | PT Powder Coated Finishes | BAC = Buy America; Buy American Act; and |
| 30R (30″) | Options: | BA Brushed Aluminum | Build America, Buy America Act Compliant. | |
| 36R (36″) | L927K | GT Gold Touch | ||
| L935K | CT Copper Touch | |||
| L940K | NT Nickel Touch | |||
| ZT Bronze Touch | ||||
| TT Toffee Touch | ||||
| PWT Pewter Touch | ||||
| BST Blackened Steel Touch |
SPECIFICATIONS
Housing: Post Powder Coated Heavy Ga. Paintlok™ Steel Housing for structural integrity, Aluminum LED bracketry for heat sinking, Rolled Aluminum Frame
LED: 3000K, 90CRI, Constant Voltage. ~7W per linear foot of mirror perimeter.
Driver: Constant voltage 0-10V dimming driver, 120/277V. (Consult factory for other options.)
Mirror: 5MM glass w/polished edges. (Optional 3/16″ silvered acrylic w/polished edges.)
Wiring: Hardwired connection for centrally located J-Box (by others).
